HDPE Floating Dredge Pipe For Sale 14Inch Plastic

Shandong Jiubei Trading Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap HDPE Floating Dredge Pipe For Sale 14Inch Plastic from wholesalers

    Buy cheap HDPE Floating Dredge Pipe For Sale 14Inch Plastic from wholesalers
    • Buy cheap HDPE Floating Dredge Pipe For Sale 14Inch Plastic from wholesalers

    HDPE Floating Dredge Pipe For Sale 14Inch Plastic

    Ask Lasest Price
    Brand Name : Jiubei
    Model Number : DN100~700
    Certification : ISO
    Price : usd50-500/m
    Payment Terms : L/C, T/T
    Supply Ability : 10000m/month
    Delivery Time : 7working days
    MOQ : 100m
    • Product Details
    • Company Profile

    HDPE Floating Dredge Pipe For Sale 14Inch Plastic

    14Inch plastic HDPE dredging pipe


    The flanged HDPE dredging pipe is easy to be connected, which reduced the swings caused by the waves and makes the medium smoother in the pipe.

    The HDPE dredging pipes are used for drainage, water-logging, dredging and sand discharging of port.


    Benefits of 14Inch plastic HDPE dredging pipe:

    a. High Corrosion Resistance

    HDPE material structure is saturated molecular group, with great chemical stability,good resistance of various corrosion mediums(acid,alkali,salt)and organic solvents.

    b. High Impact Resistance

    c. High Pressure Resistance

    d. Environment Proctection

    The manufacturing and processing of wear resistant HDPE pipe is low carbon,without wasted water,exhausted gas and waste residue,which saves 20% energy compare with the traditional steel pipes.

    e. High Flexibility

    f. Non-scaling

    g. Low energy consumption


    Dimension of HDPE dredging pipe:


    Outside Diameter(mm)

    Wall thickness(mm)
    SDR26SDR21SDR17SDR13.6SDR11
    0.4Mpa0.6Mpa0.8Mpa1.0Mpa1.25Mpa
    1104.25.36.68.110.0
    1254.86.07.49.211.4
    1606.27.79.511.814.6
    1806.98.610.713.316.4
    2007.79.611.914.718.2
    2258.610.813.416.620.5
    2509.611.914.818.422.7
    28010.713.416.620.625.4
    31512.115.018.723.228.6
    35513.616.921.126.132.2
    40015.319.123.729.436.3
    45017.221.526.733.140.9
    50019.123.929.736.845.4
    56021.426.733.241.250.8
    63024.130.037.446.357.2
    71027.233.942.152.2
    80030.638.147.458.9
    90034.442.953.366.2
    100039.247.759.373.6
    120045.957.270.6
    140053.966.782.4
    160061.676.294.2

    Technical specifications:

    Standard: ISO4427, EN12201, AS/NZS4130, DIN8074, ASTMF714, GOST18599, GB/T13663

    No.ItemRequirements
    1Elongation at break%≥350
    2Longitudinal reversion(100℃), %≤3
    3Oxidation induction time(200℃)min≥20
    4Weather resistance after the pipe has accepted the aging energy which equal to or more than 3.5GJ/㎡≤80℃ static hydraulic strength(165h)Non breakage and leakage
    Percentage of breaking-elongation,%≥350
    Oxidation induction time(200℃)min≥10

    HDPE Floating Dredge Pipe For Sale 14Inch Plastic
