Product Description:

Ultra-high molecular weight polyethylene, commonly referred to as UHMWPE, is an engineered thermoplastic with a viscosity-average molecular weight exceeding 2.0 million. It can be used in a variety of applications, including medical implants, bulletproof vests, and even fishing line.

One area where UHMWPE really shines is in its use as a pipe material. Compared to traditional HDPE materials, UHMWPE pipes offer superior performance thanks to their unique properties. These pipes have greater impact resistance, a lower coefficient of friction, and can handle higher temperatures and pressures.

This makes UHMWPE pipes an ideal choice for a variety of industries, including the oil and gas industry, chemical processing, and wastewater treatment plants. They are also commonly used in the conveyance of abrasive or corrosive materials since they are highly resistant to wear and chemical damage.

With its outstanding properties and versatility, it's no wonder that UHMWPE is quickly gaining popularity in many different fields. Its unique combination of strength, durability, and chemical resistance make it a preferred choice in a variety of applications.

Features:

UHMWPE Pipe provides a much longer life under most operating conditions due to its wear resistance which is 4-7 times greater than Q235 steel or 10 times that of HDPE (PE100) pipes.

UHMWPE Pipe has superior anti-scaling properties compared to any other pipeline on the market today because of its very smooth surface and self-lubricating properties. It prevents barnacle formation, making it a strength in the marine industry.

The collaboration of wear resistance and weight reduction means that the time between pipe replacements and/or rotations can be increased, reducing installation management constraints of lifting gear and excavation requirements. This results in lower maintenance costs, less maintenance time, less downtime, and less loss of production.

UHMWPE Pipes offer significant cost savings through increased pumping efficiency. With a surface roughness of 0.00022mm UHMWPE Pipe is extremely smooth and has resultant properties superior to PTFE (Teflon). For example, UHMWPE has a friction coefficient of 0.05, compared to 0.28 for HDPE or 0.58 for Steel (ISO 8295). This means less friction, less pressure loss, and greatly reduced energy inputs to deliver the same result.

UHMWPE pipe offers superior life to other pipeline products in acidic or corrosive applications under 85 degrees Celsius, with chemical resistance second only to PTFE (Teflon).

The strength of UHMWPE pipes offers many savings in installation costs. High compressive strength means reduced size or eliminating excavations, greater than 1.5x that of HDPE. The combination of strength and flexibility (>250% tensile elongation) means concrete bases are not required on wetlands and difficult terrain. High strength and flexibility provide greater protection against damage due to ground subsidence, earthquakes, or other unexpected movement and loading of the pipeline. UHMWPE pipes can be laid directly on the seabed.

Technical Parameters:

The UHMWPE pipe is a wear-resistant and flexible pipeline used in various industries. Its technical parameters include:

• Diameter: 1/2''-48''
• Pressure: 0.25-2.5MPa
• Thickness: 3-50mm
• Color: Black, White, Blue, Green, Yellow, Etc.
• Advantage: High Wear Resistance, High Impact Strength, etc.
• Production method: Extruding
• Temperature: -40℃~80℃

It comes with accessories like bolts, nuts, and washers. The package options include wooden case, pallet, etc. The UHMWPE floating pipeline is a reliable and durable solution for fluid transportation in harsh environments.

Applications:

The UHMWPE pipe is suitable for use in a variety of scenarios. One of the most common applications is in the transportation of chemicals and other corrosive materials. The pipe's resistance to corrosion makes it ideal for this purpose. The product is also suitable for use in water supply and drainage systems. Its large diameter makes it ideal for transporting large volumes of fluid over long distances. The pipe's smooth surface finish also reduces frictional resistance and makes it ideal for use in floating pipelines.

The UHMWPE pipe is extruded through a special process that ensures it is durable, flexible, and lightweight. Its temperature range of -40℃~80℃ makes it suitable for use in a variety of environments. The product is also available with various connection options like flange, thread, and socket to fit different installation requirements.

In summary, Jiubei's Flexible UHMWPE Pipe is a high-quality product suitable for use in a variety of applications. Its large diameter, smooth surface finish, and flexibility make it ideal for use in water supply and drainage systems, floating pipelines, and the transportation of corrosive materials. With a monthly supply capacity of 3000m, customers can be sure of a steady supply of this high-quality product.

Support and Services:

Our UHMWPE Pipe product comes with comprehensive technical support and services to ensure optimal performance and longevity. Our team of experienced engineers and technicians are available to provide assistance with installation, operation, maintenance, and troubleshooting of the product. We also offer customized solutions and product design services to meet specific customer needs. Our commitment to quality and customer satisfaction extends beyond the sale of the product, with ongoing technical support and training available to help customers maximize the benefits of our UHMWPE Pipe.
