Product Description:
Ultra-high molecular weight polyethylene, commonly abbreviated as
UHMWPE, is a type of thermoplastic used in engineering. It has an
incredibly high viscosity-average molecular weight of more than 2.0
million. This high molecular weight gives UHMWPE its unique
properties, making it an ideal material for various applications.
One particular area where UHMWPE excels is in the manufacturing of
pipes. Ultra-high molecular weight polyethylene pipe is known for
its superior performance over conventional HDPE material. It is
tougher, more abrasion-resistant, and can handle greater impact
without showing signs of damage. These characteristics make it a
popular choice in industries that require durable and long-lasting
piping solutions.
Overall, UHMWPE is a versatile material that has revolutionized the
engineering industry. Its superior properties have made it a
favorite among manufacturers, and UHMWPE pipes offer a durable and
reliable solution for any piping needs.
Features:
Longer Life
UHMWPE Pipe has exceptional wear resistance that is 4-7 times
greater than Q235 Steel or 10 times that of HDPE (PE100) pipes
under the same operating conditions. As a result, it offers far
superior life under most operating conditions.
Non-Scaling
UHMWPE Pipe has a very smooth surface and self-lubricating
properties, which gives it superior anti-scaling properties than
any other pipeline on the market today. Its non-stick factor allows
it to provide strength in the marine industry by preventing
barnacle formation.
Lower Maintenance Costs, Less Maintenance Time, Less Downtime, Less
Loss of Production
The collaboration of UHMWPE Pipe's wear resistance and weight
reduction (0.93 SG) allows for increased time between pipe
replacements and/or rotations while reducing installation
management constraints of lifting gear and excavation requirements.
This leads to lower maintenance costs, less maintenance time, less
downtime, and less loss of production.
Reduced Pumping Costs
Aside from the benefits mentioned above, UHMWPE Pipes also offer
significant cost savings through increased pumping efficiency.
UHMWPE Pipe has a surface roughness of 0.00022mm and a friction
coefficient of 0.05, compared to 0.28 for HDPE or 0.58 for Steel
(ISO 8295). This means less friction, less pressure loss, and
greatly reduced energy inputs to deliver the same result.
Chemical and Corrosion Resistance
UHMWPE Pipe offers superior life to other pipeline products in
acidic or corrosive applications under 85 degrees C. Its chemical
resistance is second only to PTFE (Teflon).
Lower Installation Costs
The strength and flexibility of UHMWPE pipes provide many savings
in installation costs. Its high compressive strength means reduced
size or eliminating excavations (greater than 1.5x that of HDPE).
It also has a combination of strength and flexibility (>250%
tensile elongation), which means concrete bases are not required on
wetlands and difficult terrain. Additionally, its high strength and
flexibility provide greater protection against damage due to ground
subsidence, earthquakes, or other unexpected movement and loading
of the pipeline. Lastly, it can be laid directly on the seabed.
Technical Parameters:
| Product Attribute | Value |
| Product Name | UHMWPE dredging pipe, UHMWPE sand dredging pipe, Large diameter
UHMWPE pipe |
| Length | 1-12m |
| Diameter | 1/2''-48'' |
| Color | Black, White, Blue, Green, Yellow, Etc. |
| Surface | Smooth,Sandblast,etc. |
| Production Method | Extruding |
| Certificate | ISO9001,CE,etc. |
| Material | UHMWPE |
| Pressure | 0.25-2.5MPa |
| Connection | Steel Flanges |
| Temperature | -40℃~80℃ |
Applications:
UHMWPE sand dredging pipe is one of the most common applications
for this product. It is used in mining, dredging, and other
industries where sand and other sediments need to be moved from one
location to another. The UHMWPE material is well-suited for this
application because it is highly wear-resistant and can withstand
the abrasive forces of sand and other sediments.
Another common application for this product is UHMWPE floating
pipeline. This type of pipeline is used in marine environments
where a floating pipeline is necessary. The UHMWPE material is
buoyant and can float on the surface of the water, making it ideal
for this application.
The Easy Installation UHMWPE pipe is another advantage of this
product. It is easy to install and requires minimal maintenance,
which makes it a cost-effective solution for a variety of
applications.
The Jiubei UHMWPE Pipe comes in a variety of sizes, ranging from
1/2'' to 48'' in diameter. It is available in black, white, blue,
green, yellow, and other colors to meet the needs of different
applications. The surface of the pipe is smooth or sandblasted,
depending on the application requirements.
The packaging details for this product are standard sea worthy
packaging, and the minimum order quantity is 100m. The price of
this product is 5-8 USD/m, and the delivery time is 14 days.
Payment terms include tt/lc, and the supply ability is 3000m/month.
Accessories such as bolts, nuts, and washers are also available
with this product.
Support and Services:
Our UHMWPE pipe product technical support team is available to
assist with any questions or issues related to the product. We
offer comprehensive technical support services, including
installation guidance, troubleshooting, and product maintenance
recommendations.
In addition, we provide a range of services to our customers, such
as product testing, custom fabrication, and on-site support. Our
goal is to ensure that our customers have the best possible
experience with our UHMWPE pipe product and are fully satisfied
with its performance and durability.
If you have any questions or concerns, please do not hesitate to
contact our technical support team. We are here to help and are
committed to providing the highest level of customer service.
